Pioneer model SA-8100 integrated amplifier in excellent condition. Rated at 40 watts RMS into 8 ohms and 45 watts RMS into 4 ohms. Built like a tank and loaded with features. This unit has been serviced and fully tested. Our original Performance Verification Report and a copy of the owner's manual included.
From Pioneer:
The SA-8100 is Pioneer's big power integrated stereo amplifier.
It features a unique twin tone control system for versatile tonal adjustment, high and low subsonic filters and high stability, reliable pure complementary OCL power amplifier design, with differential amplifier at the first stage. Large electrolytic capacitors ensure stable operation.
 |
Controls:
Bass 50Hz: -5dB -2.5dB, 0, +2.5dB +5dBclassicaudio.com
Bass 100Hz: -10dB, -7.5dB, -5dB, -2.5dB, 0 ,+10dB, +7.5dB, +5dB, +2.5dB
Treble 10kHz: -10dB, -7.5dB, -5dB, -2.5dB, 0 ,+10dB, +7.5dB, +5dB, +2.5dB
Treble 20kHz: -10dB, -7.5dB, -5dB, -2.5dB, 0 ,+10dB, +7.5dB, +5dB, +2.5dBclassicaudio.com
Balance
Volumeclassicaudio.comSwitches:
Speakers: Off, A, B, A+Bclassicaudio.com
Level Set: 0, -15dB, -30dB
Selector: Mic, Phono 1, Phono 2, Tuner, Aux 1, Aux 2
Power
Muting: -20dBclassicaudio.com
Low Filter: Off, Subsonic, 30Hz
Tone Defeat
High Filter: 8kHz
Loudnesscclassicaudio.comlassicaudio.com
Tape Monitor 1
Tape Monitor 2
Mode: Stereo Rev, Norm, L+R, L, Rclassicaudio.com
Jacks:
Headphones
Indicators:
Protection
Powerclassicaudio.com
Rear Panel:
AC Outlet Unswitched (2)
AC Outlet Switched
Mic Input (L, R)classicaudio.com
Power In (L, R)
Pre Out (L, R)
Pre/Power Mode: Normal, Separated-Subsonic Off, Separated-Subsonic On
Tape Monitor 1 Out (L, R)
Tape Monitor 1 In (L, R)classicaudio.com
Tape Monitor 2 Out (L, R)
Tape Monitor 2 In (L, R)
Tape Monitor 2 DIN
Aux 1 Input (L, R)classicaudio.com
Aux 2 Input (L, R)classicaudio.com
Phono 1 Input (L, R).
Phono 2 Input (L, R)
Phono 2 Level Trim
Aux 2 Level Trimclassicaudio.com
Speakers A (L, R)
Speakers B (L, R)classicaudio.com
Shipping Weight 35 lbs.
 |
