Marantz 4240

Specifications:

Power Output: 40 Watts X2 or 17 Watts X4 RMS into 8 ohms.
Total Harmonic Distortion: 0.5%classicaudio.com
Power Bandwidth: 10Hz to 60kHz
Damping Factor: 40 (8 ohms)
classicaudio.com
FM Sensitivity: 1.9uV (30dB Quieting)
FM THD: 0.3% Mono, 0.4% Stereo
FM Stereo Separation: 40dB (at 1 kHz)classicaudio.com

Controls:

Dolby Play Cal Left
Dolby Play Cal Rightclassicaudio.com
Dolby Record Cal Left
Dolby Record Cal Right
Dolby: FM Dolby, Play, Off, Record 1, Record 2.
Selector: AM, FM, Phono, Aux/CD4, Tape 1, Tape 2.
Mode: Mono, 2-CH, Discrete, Vari-Matrix, SQ-Decoder
Dimension: Vari-Matrix Mode Onlyclassicaudio.com
Bass: Independent Front, Rear
Treble: Independent Front, Rear
Volume
Balance: Front, Left Right (Slider)
Balance: Front, Rear (Slider)classicaudio.com
Balance: Rear, Left Right (Slider)

Switches:

Monitor: Source/Tape
Monitor: Tape 1/2classicaudio.com
Meter: Dolby Level/Signal Strength
400 Hz Tone
Hi Filterclassicaudio.com
Loudness
FM Muting
Spkr Main
Spkr Remote
Powerclassicaudio.com

Jacks:

Headphones Front
Headphones Rear

Indicators:

Dolby Level/Signal Strength Meter
Tuning Meterclassicaudio.com
STEREO
AM
FM
PHONO
4-CHclassicaudio.com
AUX
TAPE 1
TAPE 2
DOLBYclassicaudio.com

Rear Panel:

AC Outlet Unswitched
AC Outlet Switched
FM Quadradial Outputclassicaudio.com
Tape Monitor 2 Out (L, R, F, R)
Tape Monitor 2 In (L, R, F, R)
Tape Monitor 1 Out (L, R, F, R)
Tape Monitor 1 In (L, R, F, R)classicaudio.com
Aux Input (L, R, F, R)
Phono Input (L, R)
Remote Control
Power Mode: 40W X2/17W X4classicaudio.com

---
