Pioneer QC-800A

Controls:

Front Bassclassicaudio.com
Front Treble
Rear Bassclassicaudio.com
Rear Treble
Left Front Level
Right Front Levelclassicaudio.com
Left Rear Level
Right Rear Levelclassicaudio.com
Volume
Mode: 2 CH Front/Rear, 2 CH Front, 4 CH Matrix, 4 CH Discrete,
Check (CH1 + CH3).classicaudio.com
Selector: Phono 1, Phono 2, Tuner, Aux 1, Aux 2.



Switches:

Power On/Offclassicaudio.com
Low Filter On/Off
High Filter On/Off
Output On/Offclassicaudio.com
Tape Monitor 1
Tape Monitor 2classicaudio.com
Matrix Regular/SQ
Muting -20classicaudio.com

Jacks:

Headphones Frontclassicaudio.com
Headphones Rear

Indicators:

Power

Rear Panel:

Phono 1 (L, R)
Phono 2 (L, R)classicaudio.com
Tuner (L, R, F & R)
Aux 1 (L, R, F & R)classicaudio.com
Aux 2 (L, R, F & R)
Tape 1 Mon (L, R, F & R)
Tape 1 Rec (L, R, F & R)classicaudio.com
Tape 2 Mon (L, R, F & R)
Tape 2 Rec (L, R, F & R)
Output (L, R, F & R)classicaudio.com
AC Outlet Switched
