Specifications:
Power Output: 85 watts RMS per channel into 8 ohms.classicaudio.com
Power Bandwidth: 20 to 20,000 Hz at or below rated min. RMS power output and total harmonic distortion.
Total Harmonistic Distortion: less than 0.025% at or below rated min. RMS power output.
Intermodulation Distortion (70Hz : 7kHz = 4:1 SMPTE method): less than 0.025%.
Damping Factor: approximately 60 at 8 ohms.Controls:
Speakers: Off, A, B, A+B
Bass: +/- 10classicaudio.com
Treble: +/- 10
Balanceclassicaudio.com
Volume: Log dB Scale
Switches:
Powerclassicaudio.com
Treble: 6kHz/3kHz
Bass: 400Hz/200Hz
Tone: Defeat/On
Subsonic Filter: On/Off
High Filter: On/Offclassicaudio.com
Loudness: On/Off
Muting: Off/-20dB
Tape Monitor: Source, Tape 1, Tape 2classicaudio.com
Tape Copy: Tuner, Off, Source, 1>2, 2>1
Input Selector: Aux, Tuner, Phono 1, Phono 2
Jacks:
Headphonesclassicaudio.com
Indicators:
Power/Protect LEDclassicaudio.com
AUX
TUNERclassicaudio.com
PHONO 1
PHONO 2classicaudio.com
Rear Panel:
Pre-Out/Main-In (L, R)
Phono 1 (L, R)classicaudio.com
Phono 2 (L, R)classicaudio.com
Tuner (L, R)
Aux (L, R)classicaudio.com
Tape 1 Record (L, R)
Tape 1 Play (L, R)classicaudio.com
Tape 2 Record (L, R)
Tape 2 Play (L, R)classicaudio
Pre-Power Amp: Connected, Separated - Direct Coupled, Separated - Capacitor Coupled.com
AC Outlet Unswitched (2)
AC Outlet Switched (1)classicaudio.com
Speaker System A (L, R)
Speaker System B (L, R)
