Sansui G-9000DB

Specifications:

Power Output: 160 watts RMS per channel into 8 ohms.
Utilizes discrete output devices.classicaudio.com

Controls:

Bass: -2dB, -4dB, -6dB, -8dB, -10dB, 0, +2dB, +4dB, -2dB, -4dB, -6dB, -8dB, -10dB
Midrange: -2dB, -4dB, -6dB, -8dB, -10dB, 0, +2dB, +4dB, +6dB, +8dB, +10dB
Treble: -2dB, -4dB, -6dB, -8dB, -10dB, 0, +2dB, +4dB, +6dB, +8dB, +10dB
Balanceclassicaudio.com
Volumeclassicaudio.com
Selector: Aux, Phono1, Phono 2, FM Auto, AM
Tape Monitor: 1>2 Copy, Tape 1, Source, Tape 2, 2>1 Copyclassicaudio.co
Mic Mixing Levelclassicaudio.com

Switches:

Powerclassicaudio.com
Speakers A
Speakers B
Turnover: 400Hz/200Hzclassicaudio.com
Tone Defeat
Turnover: 1.5kHz/3kHz
Audio Muting: -20dBclassicaudio.com
Loudness: On/Off
Subsonic Filterclassicaudio.com
High Filter
FM Muting Offclassicaudio.com
Mode: Stereo/Mono
Dolby FM Decoder
FM Auto Noise Filterclassicaudio.com
FM IF Band: Wide/Narrow
4CH/NR Adapterclassicaudio.com

Indicators:

Left Channel Power Meterclassicaudio.com
Right Channel Power Meter
Signal Strength Meterclassicaudio.com
Tuning Meter
POWERclassicaudio.com
PROTECTOR
SPEAKER Aclassicaudio.com
SPEAKER B
STEREO
AUXclassicaudio.com
PH-2
PH-1classicaudio.com
FM
AMclassicaudio.com

Jacks:

Phones
Mic classicaudio.com

Left Side Panel:

Speakers Aclassicaudio.com
Speakers B
Pre-Out (L, R)classicaudio.com
Main-In (L, R)

Right Side Panel:

Antenna Inputs: FM 75 ohm, FM 300 ohm, AMclassicaudio.com
Adaptor Out (L, R)
Adapter In (L, R)classicaudio.com
Tape 1 Rec (L, R)
Tape 1 Play (L, R)classicaudio.com
Tape 2 Rec (L, R)
Tape 2 Play (L, R)classicaudio.com
Phono 1 (L, R)
Phono 2 (L, R)
Aux (L, R)classicaudio.com
Tape 2 Rec/Play (DIN)

Rear Panel:

AC Outlet Unswitched (2)
AC Outlet Switchedclassicaudio.com

---
